3000 Max
| Technical Specifications |
| Torque Range : |
959-2,877 Nm |
| Oil Pressure Range : |
80-240 Bar |
| Oil flow Range : |
27-75 lpm |
| Unit Weight : |
71 kg |
| Auger Diameter Range : |
100-600 mm |
| Auger Depth Range : |
1.4-3 M |
| Output Shaft Std. : |
65 mm |
| Suitable Machine Class : |
2-4 Ton |
3500 Max
| Technical Specifications |
| Torque Range : |
1,205-3,614 Nm |
| Oil Pressure Range : |
80-240 Bar |
| Oil flow Range : |
40-85 lpm |
| Unit Weight : |
73 kg |
| Auger Diameter Range : |
100-750 mm |
| Auger Depth Range : |
1.4-3 M |
| Output Shaft Std. : |
65 mm |
| Suitable Machine Class : |
2.5-4.5 Ton |
8000 Max
| Technical Specifications |
| Torque Range : |
2,717-8,152 Nm |
| Oil Pressure Range : |
80-240 Bar |
| Oil flow Range : |
70-150 lpm |
| Unit Weight : |
116 kg |
| Auger Diameter Range : |
150-1200 mm |
| Auger Depth Range : |
2.4-6 M |
| Output Shaft Std. : |
75 mm |
| Suitable Machine Class : |
6-8 Ton |
15000 Max
| Technical Specifications |
| Torque Range : |
5,024-15,071 Nm |
| Oil Pressure Range : |
80-240 Bar |
| Oil flow Range : |
80-170 lpm |
| Unit Weight : |
173 kg |
| Auger Diameter Range : |
150-1200 mm |
| Auger Depth Range : |
3.7-7.5 M |
| Output Shaft Std. : |
75 mm |
| Suitable Machine Class : |
10-15 Ton |
25000 Max
| Technical Specifications |
| Torque Range : |
16,503-24,755 Nm |
| Oil Pressure Range : |
160-240 Bar |
| Oil flow Range : |
80-170 lpm |
| Unit Weight : |
269 kg |
| Auger Diameter Range : |
150-1500 mm |
| Auger Depth Range : |
4.1-9 M |
| Output Shaft Std. : |
75 mm |
| Suitable Machine Class : |
15-22 Ton |
42000 Max
| Technical Specifications |
| Torque Range : |
24,612-42,387 Nm |
| Oil Pressure Range : |
180-310 Bar |
| Oil flow Range : |
80-225 lpm |
| Unit Weight : |
442 kg |
| Auger Diameter Range : |
300-1800 mm |
| Auger Depth Range : |
4.9-11.5 M |
| Output Shaft Std. : |
110 mm |
| Suitable Machine Class : |
20-45 Ton |
